Fiberglass Cloth Gypsum Board
product name:
Fiberglass Cloth Gypsum Board
product category:
Standard Plate, refractory plate, all-purpose plate
Product Size:
2400*1200*12.5/16mm
2440*1220*12.5/16mm
* Can be customized according to customer requirements
Packing Quantity:
| Product name | Thickness(mm) | Photo/document |
| Standard Plate | 12.5 | 80 |
| 16 | 50 | |
| Refractory Plate All-around board | 12.5 | 60 |
| 16 | 50 |
Implementation standard:
Q/0900 TTH009-2021“Gypsum based high performance fiberboard”
Combustion performance: A1 Class High Density, high strength, high grip strength
Taishan High Strength Fiberglass Plasterboard
Taishan Brand high-strength glass fiber cloth plasterboard is a new type of gypsum-based high-performance fiberboard developed by the company. The board surface adopts high-strength glass fiber cloth instead of the traditional paper cover, and with high density, high strength, high grip nail force, impact resistance, anti-cracking, anti-subsidence, green non-formaldehyde advantages, product series are: high-strength Standard Board, high-strength fire-resistant board, high-strength all-purpose board.
performance index
| Performance Index | ||||
|---|---|---|---|---|
| Name | Unit | Thickness：：：12.5cm | ||
| Taishan Standard Plate of high strength fiberglass cloth | Taishan Brand High Strength Fiberglass cloth refractory plate | Taishan Brand High Strength Glass Fiber Cloth all-purpose board | ||
| Area density | kg/㎡ | ≥10 | ≥13.5 | ≥13.5 |
| Combustion performance | — | A1 | A1 | A1 |
| Water Absorption | % | ≤8% | — | ≤8% |
| Longitudinal fracture load | N | ≥610 | ≥1046 | ≥1085 |
| Transverse fracture load | N | ≥400 | ≥519 | ≥526 |
| SHEARING force | N | ≥400 | ≥1150 | ≥1160 |
| FORMALDEHYDE | — | Formaldehyde-free | Formaldehyde-free | Formaldehyde-free |
| Internal Exposure Index IRa | — | 0 | 0 | 0 |
| External Exposure Index Ly | — | 0.1 | 0.1 | 0.1 |
-
A1 is safer if it doesn’t burn
Tested by the National Building Materials Industrial Decoration Building Materials Quality Supervision and testing center, fire grade is non-combustible A1, meeting the requirements of hotels, schools, hospitals and other building parts. -
Gao Qiang holds nails easy to construct
The vertical holding force of single self-nail is more than 30kg, which is suitable for self-nail, Air Nail, code nail and so on. -
High Strength, wear resistance and impact resistance
High-strength glass fiber cloth, high-strength Gypsum and high-strength reinforced fiber perfect combination, through the unique Gel hard board technology, the product has high-strength wear resistance and impact resistance. -
Dimensional stability, anti-deformation
Small expansion shrinkage, stable size, anti-cracking deformation. -
Formaldehyde-free, healthy, environmentally friendly
Plate does not contain any volatile harmful substances and any material containing Formaldehyde, formaldehyde-free health and more environmentally friendly.
Main application
Lamp trough, curtain box and other shapes, special firewall, fire-proof beam column, soft and hard base course lining plate, heavy load-bearing base course, tile, elevator shaft and other shaft construction, roof covering materials and exterior wall base plate.
